Our surge tanks utilise the High Pressure Walbro 525 fuel pumps, these pumps truly are in a league of their own and can support 700+HP worth of fuel each!

Our unique round design with machined top and bottom plates eliminates ANY trapped air pockets, unlike square tanks.

Now a 3 piece design means no more welds, allowing for a much nicer overall finish.

**100% E85 Compatible.

Features:
Machined from billet 6061-T6 aluminum
Staged Pumps
Insulated pumps to protect against vibration and reduce noise
Anodised gloss black to support Ethanol fuels and protect against corrosion
Stainless Steel hose clamps & Teflon submersible fuel hose
Unique electrical connectors with teflon insulators and o-ring seals to prevent leaks
All stainless steel nuts, bolts and washers.
Laser etched top plate
Rubber boots for electrical terminals
Viton o-rings used throughout
Fuel strainers to protect the pumps (when pumps are supplied)

Capacity: Single Pump Version = 2.95L Twin Pump Version = 2.86L

Fittings:
Each Pump has AN6 (-6) outlets
The other 3 ports are all AN8 (-8)

The fittings are all ORB (o-ring sealed) fittings.
